Mark

Technical specifications

1

Types of foam

Hard foam

2

suitable material dynamic viscosity（22℃）

polybasic alcohol ～2500MPas
polyisocyanate   ～1000MPas

3

Injection pressure

10～20Mpa(adjustable)

4

injection flow（mixture ratio 1：1）

500-2500g/s

5

scope of mixture

1：5～5：1（adjustable）

6

injection time

0.5～99.99S (precision up to0.01S）

7

material temperature control tolerance

±2℃

8

precision of re-injection

±1%

9

Mixture head

LX1422-2K，4 pcs of oil pipes and 2 cylinders

10

Hydraulic system

Rate of flow    10L/min
System pressure  10～20MPa

11

Tank volume

250L

12

 Polyetherpolyols metering pump

A2VK 55

13

Isocyanate metering pump

A2VK 55

14

Air-compressing requirements demands

Dry and non-oil  P：0.7Mpa
Q：600NL/min

15

Temperature control system

heating：2×4Kw

16

Power supply

3ph 5 lines，380V
